c#/vb.net 转换 excel 中的形状和 smartart 图形到图片-ag凯发旗舰厅

本文将介绍如何使用spire.xls for .net转换excel中的形状和smartart图形到图片。

原excel文档：

using spire.xls;
using system.collections.generic;
using system.drawing;
using system.drawing.imaging;
namespace convert_shapes_and_smartart_to_image
{
    class program
    {
        static void main(string[] args)
        {
            //创建workbook对象
            workbook workbook = new workbook();
            //加载excel文档
            workbook.loadfromfile("sample.xlsx");
            //获取第一个工作表
            worksheet sheet = workbook.worksheets[0];
            //创建saveshapetypeoption对象
            saveshapetypeoption shapelist = new saveshapetypeoption();
            //保存工作表中的形状和smartart图形到图片
            list images = sheet.saveshapestoimage(shapelist);
            //保存图片到指定路径
            int index = 0;
            foreach (image img in images)
            {
                img.save("image/"   "toimage"   index   ".png", imageformat.png);
                index  ;
            }
        }
    }
}

imports spire.xls
imports system.collections.generic
imports system.drawing.imaging
namespace convert_shapes_and_smartart_to_image
    friend class program
        private shared sub main(byval args as string())
            '创建workbook对象
            dim workbook as workbook = new workbook()
            '加载excel文档
            workbook.loadfromfile("sample.xlsx")
            '获取第一个工作表
            dim sheet as worksheet = workbook.worksheets(0)
            '创建saveshapetypeoption对象
            dim shapelist as saveshapetypeoption = new saveshapetypeoption()
            '保存工作表中的形状和smartart图形到图片
            dim images as list(of bitmap) = sheet.saveshapestoimage(shapelist)
            '保存图片到指定路径
            dim index as integer = 0
            for each img as image in images
                img.save("image/" & "toimage" & index & ".png", imageformat.png)
                index  = 1
            next
        end sub
    end class
end namespace

转换结果：
