本文将介绍如何使用spire.presentation for .net给ppt文档中的smartart图形的节点添加超链接。

using spire.presentation;
using spire.presentation.diagrams;
namespace smartart
{
    class program
    {
        static void main(string[] args)
        {
            //创建presentation实例
            presentation ppt = new presentation();
            //加载ppt文档
            ppt.loadfromfile("smartart.pptx");
            //获取第一张幻灯片
            islide slide = ppt.slides[0];

            //获取smartart图形
            ismartart smartart = slide.shapes[0] as ismartart;
            //添加指向网页的超链接到smartart图形的第一个节点
            smartart.nodes[0].click = new clickhyperlink("https://www.e-iceblue.com");
            //添加指向文档中指定幻灯片的超链接到smartart图形的第二个节点
            smartart.nodes[1].click = new clickhyperlink(ppt.slides[1]);
            //保存结果文档
            ppt.savetofile("result.pptx", fileformat.pptx2013);
        }
    }
}

imports spire.presentation
imports spire.presentation.diagrams
namespace smartart
    class program
        private shared sub main(byval args as string())
            dim ppt as presentation = new presentation()
            ppt.loadfromfile("smartart.pptx")
            dim slide as islide = ppt.slides(0)
            dim smartart as ismartart = trycast(slide.shapes(0), ismartart)
            smartart.nodes(0).click = new clickhyperlink("https://www.e-iceblue.com")
            smartart.nodes(1).click = new clickhyperlink(ppt.slides(1))
            ppt.savetofile("result.pptx", fileformat.pptx2013)
        end sub
    end class
end namespace

效果图：
